An Experimental Study on the Effect of Reflective Surface Variations on the Power Performance and Efficiency of Bifacial Solar Panel

Lastri Andini Gunawan; Jakariya; Ahmad Deni Mulyadi; Doane Puri Mustika; Dibyo Setiawan; Agus Subeno

doi:10.21009/JKEM.11.2.4

Authors

Lastri Andini Gunawan Politeknik Negeri Bandung
Jakariya Politeknik Negeri Bandung
Ahmad Deni Mulyadi Politeknik Negeri Bandung
Doane Puri Mustika Politeknik Negeri Bandung
Dibyo Setiawan Politeknik Negeri Bandung
Agus Subeno Institu Sains dan Teknologi Al-Kamal

DOI:

https://doi.org/10.21009/JKEM.11.2.4

Keywords:

surface albedo, reflective surface, power output, efficiency, photovoltaic system

Abstract

The increasing demand for clean electrical energy in Indonesia highlights the need to optimize solar power generation technologies. Bifacial photovoltaic (PV) panels offer higher energy yield by utilizing solar radiation from both front and rear sides; however, their performance is strongly influenced by reflective properties of the surface beneath the panel. This study aims to analyze the effect of reflective surface variations with different albedo values on the power output and efficiency of bifacial solar panels under tropical rainy season conditions. An experimental method was employed using three identical bifacial PV modules (545 Wp) installed above asphalt, paving block, and white-painted surfaces. The modules were installed with a tilt angle of 8°, an azimuth angle of 0° (facing north), and a height of 60 cm above the surface. Measurements of solar irradiance, voltage, and current were conducted at irradiance levels ranging from 203 to 1001 W/m². Data were collected three days with same conditions and parameter in November 2024 during the period time from 09:00 to 15:00. The results show that to enhance rear-side irradiance, as indicated by the increase in output power observed in this study, leading to increased output power and efficiency. The white-painted surface produced the highest performance, achieving an average power increase of approximately 9.6% and a maximum efficiency of 16.3% compared to asphalt and paving block surfaces. These findings indicate that high-albedo surfaces are an effective solution for improving bifacial solar panel performance, particularly in wet tropical climates such as Bandung, Indonesia.

References

[1] Suwarti, Wahyono, and B. Prasetiyo, “Analisis pengaruh intensitas matahari, suhu permukaan & sudut pengarah terhadap kinerja panel surya,” EKSERGI: Jurnal Teknik Energi, vol. 14, no. 3, pp. 78–85, 2018, doi: 10.32497/eksergi.v14i3.1373.

[2] A. F. Nurhasanah, Sudarti, and Yushardi, “Kajian Perubahan Iklim Terhadap Efisiensi Panel Surya,” OPTIKA: Jurnal Pendidikan Fisika, vol. 7, no. 2, pp. 366–375, 2023, doi: 10.37478/optika.v7i2.3284.

[3] D. Hamdani, K. Subagiada, and L. Subagiyo, “Analisis kinerja solar photovoltaic system (SPS) berdasarkan tinjauan efisiensi energi dan eksergi,” Jurnal Material dan Energi Indonesia, vol. 1, no. 2, pp. 84-92, 2011.

[4] S. Soewono and Jakariya, “Optimasi perbaikan faktor daya dengan pemasangan DC Reaktor akan mereduksi harmonisa di inverter motor pendingin air industri,” Jurnal Ilmiah Sutet, vol. 9, no. 2, pp. 90–111, 2019, doi: 10.33322/sutet.v9i2.562.

[5] P. Siagian, H. Alam, and R. A. Frasasti, “Efektifitas konsentrator cahaya aluminium foil terhadap kenaikan intensitas cahaya dan temperatur permukaan solar cell,” in Senashtek 2024, pp. 55–63, 2024.

[6] N. R-. Lyngskær, M. Ribaconka, M. Po, A. Thorseth, S. Thorsteinsson, C. D-. Hansen, and M. L. Jakobse, “The effect of spectral albedo in bifacial photovoltaic performance,” vol. 231, pp. 921–935, 2022, doi: 10.1016/j.solener.2021.12.023.

[7] E. M. Tonita, C. E. Valdivia, A. C. J. Russell, M. M-. Szewczyk, M. I. Bertoni, and K. Hinzer “Quantifying spectral albedo effects on bifacial photovoltaic module measurements and system model predictions,” Progress in Photovoltaics: Research and Applications, vol. 32, pp. 468–480, 2024, doi: 10.1002/pip.3789.

[8] Y. H. Anoi, A. Yani, and Yunanri, “Analisis sudut panel solar cell terhadap daya output dan efisiensi yang dihasilkan,” TURBO: Jurnal Program Studi Teknik Mesin UM Metro, vol. 8, no. 2, pp. 177–182, 2019, doi: 10.24127/trb.v8i2.1051.

[9] R. L. Yorlanda, M. D. Alfarizi, A. Apriana, Tahdid, A. Manggala, and Zurohaina, “Pengaruh kapasitas panel surya dan sudut kemiringan terhadap kinerja sistem PLTS off grid 12 volt,” Chemical Engineering Journal Storage, vol. 5, no. 5, pp. 729–743, 2025, doi: 10.29103/cejs.v5i05.23905.

[10] P. Harahap, “Pengaruh temperatur permukaan panel surya terhadap daya yang dihasilkan dari berbagai jenis sel surya,” RELE (Rekayasa Elektrikal dan Energi): Jurnal Teknik Elektro, vol. 2, no. 2, pp. 73–80, 2020, doi: 10.30596/rele.v2i2.4420.

[11] E. Yusuf, Jakariya, and A. Subeno, “Planning for the development of a 40 kWp off-grid centralized solar power plant (SPP) on Insumbabi Island,” Jurnal Konversi Energi dan Manufaktur, vol. 10, no. 2, pp. 127–139, 2025, doi: 10.21009/jkem.10.2.4.

[12] V. d’Alessandro, S. Daliento, M. Dhimish, and P. Guerriero, “Albedo reflection modeling in bifacial photovoltaic modules,” Solar, vol 4, no. 4, pp. 660-673, 2024. doi: 10.3390/solar4040031.

[13] Y. Kotak, M. S. Gul, T. Muneer, and S. M. Ivanova, “Investigating the impact of ground albedo on the performance of PV systems,” in CIBSE Technical Symposium, pp. 1–16, 2015.

[14] H. Kim, Y. Gao, E. Moran, A. Howle, S. McSherry, S. Cira, and A. Lenert, “High albedo daytime radiative cooling for enhanced bifacial PV performance,” Nanophotonics, vol. 13, no. 5, pp. 621–627, 2024, doi: 10.1515/nanoph-2023-0611.

[15] R. A. Rahman, N. Plamonia, D. Setiawan, and R. D. D. Putra, “Development and thermal investigation of modified octadecanoic acid as energy storage material,” Chemistry & Chemical Technology, vol. 18, no. 4, pp. 615–622, 2024, doi: 10.23939/chcht18.04.615.

[16] Jakariya, L. Wijayantib, M. Mulyadi, D. Setiawan, H. Maksum Ardi, and Rani Anggrainy, “Studi perencanaan ulang perpipaan sistem filtrasi air skala rumah tangga,” Jurnal Permadi: Perancangan, Manufaktur, Material dan Energi, vol. 5, no. 3, pp. 123-131, 2023, doi: 10.52005/permadi.v5i03.120.

[17] H. L. Tan, B. H. Lim, M. H. Tan, X. Zeng, K. K-. Chong, K. H. Chua, and Y. Zhang, “Investigation of bifacial gain and albedo of bifacial photovoltaic modules that operate in a tropical site,” in 2024 8th International Conference on Green Energy and Applications (ICGEA), pp. 265–270, 2024, doi: 10.1109/ICGEA60749.2024.10560565.

[18] S. Saodah, B. Eliana, and J. Jakariya, “Studi pengaruh penuaan minyak trafo terhadap karakteristik dielektrik,” JITEL (Jurnal Ilmiah Telekomunikasi, Elektronika, dan Listrik Tenaga), vol. 3, no. 2, pp. 83–90, 2023, doi: 10.35313/jitel.v3.i2.2023.83-90.

[19] Isdawimah, N. Nadhiroh, Muchlishah, D. Monika, A. K. Wardhany, and A. B. Kusumaningtyas, “Pemanfaatan reflektor untuk peningkatan daya luaran panel surya pada sistem off grid,” Jurnal Poli-Teknologi, vol. 21, no. 3, pp. 97-106, 2022, doi: 10.32722/pt.v21i3.4723.

[20] H. S. Tira, A. Natsir, and T. Putranto, “Kinerja modul surya melalui variasi solar collector dan kecepatan angin,” Dinamika Teknik Mesin: Jurnal Keilmuan dan Terapan Teknik Mesin, vol. 10, no. 1, pp. 25-32, 2020, doi: 10.29303/dtm.v10i1.302.

[21] S. P. Mallick, D. P. Dash, S. Mallik, R. Roshan, S. Mahata, P. Das, and S. S. Mahato, “An empirical approach towards photovoltaic parameter extraction and optimization,” Solar Energy, vol. 153, pp. 360–365, 2017, doi: 10.1016/j.solener.2017.05.076.

[22] Z. O. Priani, H. Batih, and S. Abduh, “Pengaruh suhu dan durasi penyinaran panel surya terhadap efisiensi energi panel surya: studi kasus PLTS institut teknologi PLN,” Integrative Perspectives of Social and Science Journal (IPSSJ), vol. 2, no. 3, pp. 5201-5228, 2025.

[23] R. Pido, B. H. Rahmat, R. Wawan, and D. R. Rianto, “Pengaruh variasi aliran udara terhadap optimasi daya panel surya,” Dinamika Teknik Mesin, vol. 13, no. 2, pp. 189-195, 2023, doi: 10.29303/dtm.v13i2.661.

[24] R. Barokah, N. N. Suryaman, and A. Rajani, “Experimental study of bifacial solar panels with reflective surface variations in bandung, indonesia,” REM (Rekayasa Energi Manufaktur) Jurnal, vol. 10, no. 2, pp. 81-88, 2025, doi: 10.21070/r.e.m.v10i2.1758.

[25] M. Alam, M. S. Gul, and T. Muneer, “Performance analysis and comparison between bifacial and monofacial solar photovoltaic at various ground albedo conditions,” Renewable Energy Focus, vol. 44, pp. 295–316, 2023, doi: 10.1016/j.ref.2023.01.005.
